Black TV / SAT Wall Plate with Integrated Diplexer

by Conversions Tech
Availability:
14 in stock, ready to be shipped
$6.50 - $6.50
$6.50
$6.50 - $6.50
$6.50
Request Distributor or Volume Pricing
SKU 5510-998



Black TV / SAT Wall Plate with Integrated Diplexer 4K-Ready

Conversions Tech™ packs a precision wide-band diplexer, dual F-type connectors, and a matte-black Decora faceplate into one installer-friendly module. Route satellite and terrestrial signals down a single RG-6, then split them cleanly at the outlet—zero messy pigtails, zero signal headaches.

Key Benefits

  • Wide-Band Split: 5 – 862 MHz (TV/OTA) ↔ 950 – 2150 MHz (SAT)
  • Ultra-Low Insertion Loss: ≤ 0.5 dB TV, ≤ 1 dB SAT—perfect for 4 K UHD & ATSC 3.0
  • High Port Isolation: > 25 dB prevents LO leakage and cross-band interference
  • Machined F-Connectors: nickel-plated brass shells, gold-plated center pins
  • Matte-Black ABS: UV-stabilized, fingerprint-resistant, blends with modern AV décor
  • Raised Legends: “TV” and “SAT” are hot-stamped for lifetime visibility
  • NEC-Compliant Ground Strap: direct bond to wall-box ground screw

Technical Specifications

Parameter TV Port SAT Port
Frequency Range 5 – 862 MHz 950 – 2150 MHz
Insertion Loss (typ.) ≤ 0.5 dB ≤ 1 dB
Return Loss ≥ 18 dB ≥ 14 dB
Port-to-Port Isolation > 25 dB
Power Passing Blocked 500 mA @ 24 V DC
Impedance 75 Ω nominal
Environmental & Mechanical
Operating Temperature −40 °C … +60 °C
Faceplate Material UL-94 V-0 ABS, matte black
Dimensions (H × W × D) 4.5 × 2.75 × 1.2 in  (114 × 70 × 31 mm)
Shipping Weight 3.1 oz (88 g)

Ideal Installations

  • Single-cable satellite + OTA drops in homes, condos, MDUs, hotels
  • Retrofit upgrades where conduit space is tight
  • DirecTV®, DISH®, free-to-air & ATSC 3.0 antenna distribution

Compliance & Certifications

  • SCTE / ISO/IEC 11801 Class E performance
  • ROHS 3 & REACH compliant
  • NEC Article 820 bonding & grounding compatible
