Battery Cable Lugs — 6221 Series, Bare & Tinned Copper
6221 Series copper battery cable lugs, 4 AWG through 4/0 — seamless one-piece copper tube with flared entry and stamped gauge, in bare copper and electro-tin plated, 1/4" to 1/2" studs. Crimp or solder; 600 V, UL 486A class. For battery banks, inverters, starters, grounds, UPS strings, and welding leads. Stocked; same-day shipping by 2PM ET; Net-30 for trade accounts.
Choosing: the lug gauge must equal the cable gauge; the stud matches the terminal (5/16" and 3/8" on most batteries and inverters, 1/4" on chargers and small bus bars, 1/2" on large bus and disconnects). Tinned for marine, engine bay, and any wet or salt exposure (ABYC E-11); bare copper for dry interiors, sealed with adhesive-lined heat shrink. Crimp with a hex die matched to the gauge — ABYC prohibits solder as the sole connection. Sizing from inverter wattage, torque values, and installation checklist: Battery Cable Lug Sizing Guide.
Cross-reference
| Size | Quick Cable (D 1/4" · E 5/16" · F 3/8") | Burndy HYLUG YA-L (short barrel) | Panduit LCA | Del City (bare) |
|---|---|---|---|---|
| 4 AWG | 5952D / E / F | YA4CL2 (1/4"), YA4CL (5/16"), YA4CL4 (3/8") | LCA4-14 / -56 / -38 | 906505 / 906605 / 906805 |
| 2 AWG | 5953D / E / F | YA2CL2, YA2CL, YA2CL4 | LCA2-14 / -56 / -38 | 906525 / 906625 / 906825 |
| 1 AWG | 5954D / E / F | YA1CL2, YA1CL, YA1CL4, YA1CL6 | LCA1-14 / -56 / -38 / -12 | 906535 / 906635 / 906835 |
| 1/0 AWG | 5955D / E / F | YA25L2, YA25L, YA25L4, YA25L6 | LCA1/0-14 / -56 / -38 / -12 | 906545 / 906645 / 906845 |
| 2/0 AWG | 5956D / E / F | YA26L2, YA26L3, YA26L, YA26L6 | LCA2/0-14 / -56 / -38 / -12 | 906555 / 906655 / 906855 |
| 3/0 AWG | 5957E / F | YA27L3, YA27L4, YA27L | LCA3/0-56 / -38 / -12 | 906665 / 906865 |
| 4/0 AWG | 5958D / E / F | YA28L2, YA28L3, YA28L4, YA28L | LCA4/0-14 / -56 / -38 / -12 | 906575 / 906675 / 906875 |
Crosses identify lugs of the same conductor size, stud, and 600 V construction class. Burndy numbers omit the stud digit at each size's catalog default (2 = 1/4", 3 = 5/16", 4 = 3/8", 6 = 1/2"); Panduit numbers take a package suffix (-X, -Q). Related: 90° Flag Lugs · Busbars & Fuse Blocks · Contractor & distributor pricing →
