LL Series (Non-Thread) 2" Conduit Fitting — Heavy-Duty 90° Electrical Elbow
Overview
The LL Series non-thread 2" conduit elbow enables a controlled 90° directional change for large-format metallic conduit runs while preserving conductor pull efficiency and enclosure ingress protection. Its non-threaded interface accelerates installation on big-bore systems, avoiding cross-thread damage and maintaining conduit wall integrity—ideal for code-compliant power distribution and feeder circuits across industrial, commercial, utility, and large residential projects.
Description
Engineered from die-cast zinc or aluminum alloy, this 2" LL body incorporates an optimized internal radius that minimizes jacket abrasion and pulling tension on high-ampacity conductors. The removable left-side cover provides ample access for wire pulling, terminations (where permitted), and inspection; when used with the supplied gasket (model dependent), the assembly supports damp-location service. The non-threaded mounting integrates with set-screw or compression connectors per conduit type, delivering rigid mechanical retention and dependable electrical continuity in demanding environments.
Specification
Applications & Use Cases
- Execute a 90° bend for large-diameter conduit when routing around structural members and equipment.
- Provide a protected, serviceable entry into gear, pull boxes, MCCs, switchboards, and NEMA enclosures.
- Enable rapid installation on feeder circuits without threading or reaming conduit ends.
- Support indoor/outdoor distribution in plants, warehouses, treatment facilities, data centers, and infrastructure.
- Maintain pull-through accessibility for heavy conductors during commissioning and maintenance cycles.
Key Features
FAQs
Is the 2" LL elbow suitable for high-ampacity feeders?
Yes. The large internal radius and rigid construction support feeder-grade conductors, reducing pulling stress and maintaining pathway integrity.
What does “LL” specify on a 2" conduit body?
“LL” denotes a 90° conduit body with a left-side removable cover for pulling and inspection access.
How is a non-threaded 2" elbow secured?
Use set-screw or compression connectors matched to EMT, IMC, or rigid conduit. No threading is required.
Does the 2" model include a cover and gasket?
Many LL variants ship with a cover and gasket for damp-location use. Verify the contents of your specific model.
Can I deploy this fitting outdoors?
Yes—when properly sealed and paired with corrosion-resistant finishes, it is suitable for outdoor and damp-location service per code.
What’s the bend advantage at 2" size?
The optimized radius reduces jacket abrasion and pulling force, critical for heavy multi-conductor installations.
Is it compatible across EMT, IMC, and rigid?
Yes. It is designed for all three metallic conduit systems when used with the appropriate connector type.
How does it align with NEC requirements?
The body design meets applicable NEC provisions for fittings, providing mechanical protection, continuity, and service access.
Do I need special tools for 2" installation?
No threading tools are needed. Standard electrician’s hand tools are sufficient for connectors and cover hardware.
How do LL, LR, and LB differ at 2"?
LL has a left-side cover, LR a right-side cover, and LB a back-side cover—choose based on run direction and service access.
Can I order replacement covers/gaskets for the 2" size?
Yes. Source genuine replacements from Conversions Tech or authorized distributors for fit and sealing performance.
