Copper Compression Dual-Tap H-Tap
Shipping calculated at checkout
SKU: 8882-007
Out of stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
Designed for electricians who need two tap take-offs from a single feeder, the 8882-007 delivers proven electrical integrity with shorter lead times, a lifetime warranty, and distributor-friendly pricing that keeps your bids competitive without slicing margins.
Spec-for-Spec Match-Up
| Feature | CT-8882-007 | Comparable Industry Spec |
|---|---|---|
| Run (Main) Conductor Range | 250 MCM – 2 AWG Cu | 250 MCM – 2 AWG Cu |
| Tap 1 Conductor Range | 2 AWG – 6 AWG Cu | 2 AWG – 6 AWG Cu |
| Tap 2 Conductor Range | 8 AWG – 14 AWG Cu | 8 AWG – 14 AWG Cu |
| Die Index / Crimps | 654 / 1 crimp per barrel | 654 / 1 crimp per barrel |
| Voltage Rating | 35 kV | 35 kV |
| Material / Finish | Tin-plated electrolytic copper | Tin-plated electrolytic copper |
| Temperature Rating | −40 °C to +90 °C (−40 °F to 194 °F) | −40 °C to +90 °C |
| Overall Dimensions (L × W × H) | 0.90 in × 0.90 in × 1.52 in | 0.90 in × 0.90 in × 1.52 in |
| Listings & Compliance | UL 486A-486B, CSA C22.2 No. 65, RoHS | UL 486A-486B, CSA Listed |
| Cover Included | Clear, UL 94 V-0, snap-on | Clear, UL 94 V-0 |
| Warranty | Lifetime “No-Questions” Replacement | Standard manufacturer warranty |
| Typical Distributor Cost* | ▼ 25 – 30 % below web list | Market average |
*Actual discount varies by volume and territory.
Five Reasons to Switch
- Healthy Margins – factory-direct pricing and pallet-level MOQ boost branch GP.
- Dual-Tap Convenience – one connector handles a service feed plus two sub-circuits—perfect for PV combiner boxes and panelboard retrofits.
- Inspection-Ready Clear Cover – UL 94 V-0 material lets AHJs verify crimp quality instantly.
- QR-Enabled Packaging – on-carton code links to a die-selector app and 60-second install video.
- Lifetime Warranty – if it ever fails under normal service, we replace it—period.
Typical Applications
- Tap-offs in switchboards, split-bus panels & MCC buckets
- Battery-storage jumpers & solar combiner box take-offs
- Utility service-entrance splices with branch circuits
- Grounding loops and lightning protection where two down-conductors are required
- Rail, marine & mining power distribution needing compact, dual-tap terminations
Tech data for CT-8882-007 is derived from Conversions Tech engineering documents and is subject to change without notice. Always verify conductor compatibility and crimp tooling before installation.
Cross-reference: Burndy® YH292CWCC
4 Reasons Pros Buy Direct from Conversions Tech
, we design, test, and ship every product from inside the United States— “” quality without the big-box markup.
Our , mold, and QA station behind our weatherproof boxes, conduit bodies, and power inverters. , UL-listed safety, and up to 30 % lower cost than .
Need a torque spec or an OEM quote at dawn? You’ll speak directly with the Conversions Tech engineering desk—not a script reader—for instant answers, custom kitting, and private-label options.
Bottom line: For rugged, code-compliant electrical solutions shipped fast from a trusted U.S. source, choose Conversions Tech and build it right the first time.
