MPPT Solar Charger Controller 40A, 12V/24V auto 100V max solar voltage
Shipping calculated at checkout
Out of stock
Conversions Tech 40 Amp MPPT Solar Charge Controller
Harvest every ray. This 40 A MPPT controller leverages cutting-edge Max Power Point Tracking to pull up to 98 % of panel output into your battery bank—even under shifting clouds or partial shade. Perfect for telecom repeaters, off-grid cabins, RV rigs, and commercial arrays.
Top-Line Advantages
- > 99.9 % MPPT Accuracy – Locks onto the true watt sweet spot in milliseconds.
- Digital 4-Stage Charging – MPPT → Boost → Equalize → Float maximizes capacity & battery life.
- Auto 12 / 24 V Detection – Zero-config start-up for common systems.
- Multi-Chemistry Ready – Flooded, AGM, Gel, and LiFePO4 profiles built-in.
- RS-485 / Modbus + Bluetooth – Real-time data, firmware updates, and IoT dashboards.
- Thermal Derating + Oversize Heat Sink – Keeps components protected in desert heat.
Technical Specifications
Rated Charge / Load Current | 40 A |
---|---|
System Voltage | Auto 12 V / 24 V |
Max PV Input Voltage | 75 V |
MPPT Tracking Range | 120 W – 960 W (12 V) / 240 W – 1920 W (24 V) |
Tracking Efficiency | > 99.9 % |
Charge Conversion Efficiency | Up to 98 % |
Battery Types | Sealed, Flooded, AGM, Gel, Lithium (LiFePO₄) |
Communication | RS-485 Modbus (RJ-11), optional Bluetooth / IoT GPRS |
Operating Temp | -31 °F – 131 °F (-35 °C – 55 °C) |
Dimensions | — |
Weight | — |
Ideal Applications
- Solar telecom base stations & remote repeaters
- Off-grid cabins, tiny homes & battery storage
- Commercial / utility PV installations requiring RS-485 data
- RV, van-life & marine systems upgrading to lithium
