Non-Metallic 90° Angle Liquid Tight Connector - 1"

Product Overview

The Non-Metallic 90° Angle Liquid Tight Connector is specifically designed to provide a secure and dependable connection for liquid-tight conduit systems that require a right-angle configuration. Constructed from high-quality 6/6 Nylon material, it is engineered to withstand demanding environmental conditions, offering robust protection for electrical systems. This connector is equipped with a UL (Underwriters Laboratories) mark for safety and compliance, and it is available in a 1-inch size, ideal for use in a variety of electrical and industrial applications.

Description

The Non-Metallic 90° Angle Liquid Tight Connector is an essential component for connecting liquid-tight flexible conduit to junction boxes, panels, or other equipment in a 90-degree angled configuration. Its 6/6 Nylon material ensures durability, flexibility, and resistance to environmental factors such as UV radiation, chemicals, and moisture. This connector helps maintain a secure, sealed connection, preventing leaks and protecting the electrical wiring from external elements.

It is a UL-certified component, meeting rigorous safety standards. The 1-inch size fits standard conduit systems, making it versatile for both residential and industrial use. The grey color provides a clean, professional appearance and is ideal for a range of installations.

Specifications

• Product Type: 90° Angle Liquid Tight Connector
• Material: 6/6 Nylon
• Color: Grey
• Size: 1 inch (for use with 1-inch conduit)
• UL Mark: Yes (Underwriters Laboratories certified)
• Temperature Rating: -40°C to 90°C (-40°F to 194°F)
• IP Rating: Typically IP65 or IP67, providing dust-tight and water-resistant protection
• Compliance: UL 514B, CSA C22.2 No. 18, RoHS Compliant
• Application: Indoor and outdoor use

Product Features

• 90° Angle Configuration: Ideal for applications that require a right-angle conduit connection for space-saving or specific installation needs.
• Non-Metallic Construction: Made from durable 6/6 Nylon, offering resistance to UV light, chemicals, and corrosion.
• Liquid Tight: Provides a secure, moisture-resistant connection to protect electrical systems from liquids and contaminants.
• UL Certified: Meets stringent safety standards, ensuring a reliable, high-quality connection for electrical systems.
• Easy Installation: Designed for quick and efficient installation, with a simple threaded design for secure attachment to conduit and junction boxes.
• Durability: Resistant to temperature extremes and environmental stress, ensuring long-lasting performance in harsh conditions.
• Grey Color: Neutral color that blends seamlessly with most installations, ideal for industrial and residential environments.

Cases & Uses

• Industrial Environments: Perfect for factories, warehouses, and industrial applications where space is limited and a liquid-tight, right-angle connection is required.
• Outdoor Applications: Suitable for use in electrical panels, junction boxes, and outdoor equipment installations where moisture and dust resistance are critical.
• Residential Wiring: Provides protection for electrical circuits in areas prone to moisture, such as basements, garages, or outdoor electrical outlets.
• Marine and Boat Installations: Protects electrical systems in marine environments, where corrosion and moisture resistance are essential.
• Agricultural Installations: Ideal for farms and greenhouses where electrical systems are exposed to water, dust, and other environmental elements.
• Lighting Systems: Commonly used in outdoor lighting, streetlights, or signage where the conduit needs to be angled for efficient routing and protection.
