Copper Short Barrel Two Hole Compression Lugs 4/0 AWG 3/8-inch Bolt Size
Shipping calculated at checkout
SKU: 210-09944
1000 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The Conversions Tech 2-hole lug is a highly reliable copper compression lug engineered for secure electrical connections. Designed for 4/0 conductor size, this lug features a 3/8-inch bolt size, a standard barrel, and an integrated sight window that allows for easy visual inspection of the connection. Its tin plating ensures enhanced corrosion resistance and longevity, while the distinctive Yellow color code offers quick identification and ensures compatibility with standard color-coding systems. This durable and efficient lug is built to provide long-lasting performance in a variety of electrical applications.
Key Features
- Copper Construction – Ensures reliable and efficient electrical conductivity.
- 4/0 Conductor Size – Designed specifically for 4/0 wire, ensuring compatibility with larger conductors.
- 3/8-inch Bolt Size – Standard bolt size for secure and easy connections.
- Standard Barrel – Provides a typical barrel shape for straightforward wire insertion and compression.
- Sight Window – Allows for visual inspection of the connection, ensuring proper crimping and reliability.
- Tin Plating – Offers enhanced corrosion resistance, extending the lug's lifespan.
- Yellow Color Code – Easy identification and ensures compatibility with standard color-coding systems for quick recognition.
Technical Specifications
| Material | Seamless Electro-Tin Plated Copper |
|---|---|
| Color | Yellow |
| Overall Length | 3.303 Inches |
| Barrel Length | 0.875 Inches |
| Conductor Material | Copper |
| Voltage Rating | 35 kV |
| Conductor Size | 4/0 AWG |
| Stud Size | 3/8 Inch |
| Die Index | I-54 |
| Pad Size | 1.937 Inch Length x 0.999 Inch Width x 0.141 Inch Thickness |
| Pad Holes | 2 |
| Pad Hole Spacing | 1 Inch |
| Barrel Size | 0.546 Inch Inner Diameter x 0.687 Inch Outer Diameter |
| Barrel Entry Type | Chamfered |
| Temperature Rating | 90°C |
