Copper Long Barrel One Hole Compression Lug 600 MCM 1/2-inch Bolt Size
Shipping calculated at checkout
SKU: 210-98081
2000 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The Conversions Tech durable copper compression lug designed for a 600 MCM conductor size. It features a single 1/2-inch bolt hole, a long barrel construction, and a reliable tin-plated finish, ensuring secure electrical connections. The lug is easily identifiable with its distinctive green color code, making it an ideal choice for various electrical applications. Its high-quality construction guarantees efficient conductivity and long-lasting performance in demanding environments.
Key Features
- Copper Construction – Made from high-quality copper, providing excellent conductivity for reliable and efficient electrical connections.
- 600 MCM Conductor Size – Designed for 600 MCM wire, ideal for use in medium to large electrical systems.
- 1/2-inch Bolt Hole – Features a single 1/2-inch bolt hole for secure attachment and stable connections.
- Long Barrel Design – The long barrel construction ensures a strong, stable connection and proper compression.
- Tin Plating – Tin-plated finish provides enhanced corrosion resistance, ensuring durability and performance in various environments.
- Green Color Code – The distinctive green color code allows for quick identification and ensures compatibility with color-coding systems.
-
Durable and Reliable – Engineered for long-lasting performance, this lug ensures secure electrical connections even in demanding conditions.
Technical Specifications
| Material | Seamless Electro-Tin Plated Copper |
|---|---|
| Color | Green |
| Overall Length | 4.933 Inch |
| Barrel Length | 2.687 Inch |
| Conductor Material | Copper |
| Voltage Rating | 35 kV |
| Conductor Size | 600 MCM |
| Stud Size | 1/2 Inch |
| Die Index | I-94 |
| Pad Size | 1.437 Inch L X 1.712 Inch W X 0.267 Inch Thk |
| Pad Hole(s) | 1 |
| Barrel Type | Long |
| ID/OD | 0.92 Inch ID X 1.187 Inch OD |
| Barrel Entry | Chamfered |
| Temperature Rating | 90 Deg C |
