Copper Long Barrel Two Hole Compression Lugs 1/0 AWG 1/2-inch Bolt Size
Shipping calculated at checkout
SKU: 210-98097
1000 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The Conversions Tech Copper Compression Lug is specifically designed for 1/0 conductor size, featuring a long barrel for added stability and two holes with 1-3/4 inch spacing for versatile installation options. Its tin-plated finish ensures superior durability and conductivity, making it a reliable choice for demanding electrical environments.
Key Features
- Designed for 1/0 conductor size - Specifically engineered to accommodate 1/0 gauge cables.
- Long barrel construction - Provides added stability and ensures a secure connection.
- Two holes with 1-3/4 inch spacing - Offers versatile installation options for different setups.
- Tin-plated finish - Enhances durability and ensures excellent conductivity, while also providing corrosion resistance.
- Superior durability - Built to withstand demanding electrical environments and provide long-lasting performance.
-
Reliable choice for electrical applications - Ensures secure and efficient connections in various electrical systems.
Technical Specifications
| Material | Electro-Tin Plated Copper |
|---|---|
| Color | Pink |
| Overall Length | 4.856 inches |
| Barrel Length | 1.5 inches |
| Conductor Material | Copper |
| Voltage Rating | 35 kilovolts |
| Conductor Size | 1/0 AWG |
| Stud Size | 1/2 inch |
| Die Index | I-42 |
| Pad Size | 3 inches L x 0.738 inches W x 0.125 inches Thk |
| Pad Holes | 2 |
| Pad Hole Spacing | 1-3/4 inches |
| Barrel Type | Long |
| Size | Inner Diameter 0.39 inches, Outer Diameter 0.515 inches |
| Cable Entry Type | Chamfered Entry |
| Temperature Rating | 90°C |
