Short Barrel Compression Splice 4/0 AWG Copper | 35kV, 90°C, Purple Code
Shipping calculated at checkout
SKU: 210-98119
32 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
Short barrel compression splice for 4/0 AWG copper conductors. Center wire stop design with chamfered barrel ends for controlled conductor insertion. Used in power distribution panels, industrial machinery, renewable energy systems, electrical substations, commercial construction, data centers, telecommunications, and utility power grids. Tin-plated seamless copper construction provides conductivity and corrosion resistance. Purple color code enables quick size identification during installation.
Specifications
- Type: Center Wire Stop
- Barrel Type: Short With Chamfered End
- Conductor Size: 4/0 AWG
- Expanded Wire Size Compatibility: 1 to 4/0 AWG
- Length: 2.125 inches
- Inner Diameter: 0.546 inches
- Outer Diameter: 0.687 inches
- Conductor Material: Copper
- Body Material: Electro-Tin Plated High Strength Seamless Copper
- Voltage Rating: 35 kV
- Temperature Rating: 90°C
- Color Code: Purple
- Certifications: UL Certified, RoHS Compliant
Cross-Reference
Equivalent to industry-standard short barrel compression splices for 4/0 AWG copper conductors. Comparable form factor to Thomas & Betty, Burndy, and Panduit short barrel splices with purple color code designation.
FAQ
What does "expanded wire size compatibility 1 to 4/0 AWG" mean for installation?
The barrel accommodates a range of conductor sizes from 1 AWG through 4/0 AWG. Use the appropriate die index and compression force for the specific conductor size being spliced. Verify crimp dimensions with manufacturer tooling specifications.
What crimp tool and die are required?
The source does not specify tooling requirements. Use UL-listed compression tooling with dies appropriate for short barrel splices, 4/0 AWG conductor size, and center wire stop design. Follow die index markings for the specific connector color code.
