Copper Long Length Compression Connector 250 MCM
Shipping calculated at checkout
SKU: 212-5250
900 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The Conversions Tech 250 MCM Copper Compression Connector is specifically designed for conductor size 250 MCM, featuring a long barrel for enhanced conductivity and stability. The tin-plated copper provides excellent corrosion resistance, ensuring longevity in diverse environments. Its blue color code aids in quick identification during installation, making it an ideal choice for high-stakes electrical applications.
Specifications
Type: Center Wire Stop
Length: 3.875 inches
Inner Diameter: 0.59 inch
Outer Diameter: 0.75 inch
Conductor Material: Copper
Voltage Rating: 35 kV
Body Material: Electro-Tin Plated High Strength Seamless Copper
Conductor Size: 250 MCM
Color Code: Blue
Barrel Type: Long with Chamfered End
Application: Grounding and Bonding
Temperature Rating: 90°C
Applications
- Power Distribution Panels
- Industrial Machinery
- Renewable Energy Systems
- Electrical Cabinets and Enclosures
- Commercial Buildings
- Construction Sites
- Telecommunications Infrastructure
- Data Centers
- Grounding and Bonding Applications
Key Features
- Optimized for 250 MCM conductors, providing a secure fit and enhanced electrical performance.
- Constructed from high-strength seamless copper that is electro-tin plated, offering both superior conductivity and corrosion resistance.
- The long barrel design with a chamfered end facilitates easier wire insertion and a stable connection.
- Blue color coding ensures quick and accurate installation, aligning with industry standards.
Download our detailed specification sheet and drawing for more information:
Download Specification Sheet Download Drawing
