CT-T2H1-1000 Mechanical Lug — 2-Conductor 1-Hole Dual-Rated AL/CU (2) 500–1000 kcmil 5/8in Stud
Shipping calculated at checkout
SKU: CT-T2H1-1000
In stock
Open here
Made to order. This size ships from our production line, typically 6–8 weeks. Volume pricing and expedite options: trade desk.
The Conversions Tech CT-T2H1-1000 is a dual-rated mechanical lug for terminating up to 2 aluminum or copper conductors ((2) 500-1000 kcmil) with a reusable set-screw connection - no crimp tool or dies required. Machined from 6061-T6 aluminum alloy and electro tin plated for low contact resistance and corrosion protection.
| Specifications | |
| Conductor range | (2) 500-1000 kcmil (AL/CU dual rated) |
| Conductors | 2 |
| Mounting stud | 5/8 |
| Material / finish | 6061-T6 aluminum, electro tin plated |
| Rating | 600 V, 90C, UL 486A/B Listed |
Standard termination hardware for load centers, panelboards, safety switches, transformers, and transfer switches. Ships same day when ordered by 2 PM ET.
Specifications
| Part Number | CT-T2H1-1000 |
| Category | Electrical connector |
| Configuration | 2 |
| Stud Size | 5/8" |
| Weight | 1.2 lb (est.) |
| HS Code | 8536.90.4000 |
Cross-Reference: CT-T2H1-1000
| Brand | Part | Notes |
|---|---|---|
| ILSCO ClearChoice | AU-1000* | 2-conductor dual-rated mechanical lug, same class; ILSCO TA-2/0 street price runs + vs CT |
| Blackburn (ABB) | ADR1000* | dual-rated mechanical series |
| Burndy | KA series* | match by wire range 500–1000 kcmil and stud |
*Cross by published wire range/stud specifications - verify fit for your application. Trademarks belong to their owners. Dual-rated AL/CU mechanical lug, tin-plated aluminum body, 500–1000 kcmil, stud, 2-hole mount, UL 486A/B class.
