1000 ft Bulk Green Cat5e Ethernet Cable – Solid 24 AWG Copper, CMR Riser | Conversions Tech™
Fuel flawless Gigabit-speed LAN builds with Conversions Tech™ Green Cat5e bulk cable. Precision-twisted UTP pairs crafted from solid 24 AWG 100 % bare copper punch through crosstalk, EMI, and insertion loss—delivering clean data streams and robust PoE power up to 328 ft (100 m). A tough yet flexible CMR (UL-Listed) riser jacket meets fire-safety codes for vertical runs in walls or between floors, while our easy-feed tangle-free pull-box shaves hours off large installations.
Key Performance Advantages
- Pure Copper Conductors – Oxygen-free 24 AWG solid copper unlocks true Cat5e bandwidth & maximizes PoE efficiency (up to 90 W, IEEE 802.3bt).
- True Gigabit Certification – Factory-tested to 350 MHz, surpassing TIA/EIA-568-C.2 specs for error-free 10/100/1000 BASE-T and IP camera backbones.
- CMR Riser Safety – Flame-retardant PVC resists smoke propagation in vertical shafts; ETL-verified and RoHS compliant.
- UTP Geometry – Precisely balanced twists tamp down near-end crosstalk (NEXT) without bulky shielding—lighter, more flexible pulls.
- Pro-Grade Pull-Box – Tactical payout design cuts drag and kinks, keeping runs smooth and job sites frustration-free.
- Color-Coded Green – Rapid identification and tidy cable management in dense racks or patch fields.
- Lifetime Limited Warranty – Backed by Conversions Tech’s rock-solid support for total peace of mind.
Technical Specifications
Cable Type | Category 5e (ANSI/TIA-568-C.2) |
---|---|
Conductor Material | 99.99 % bare copper, solid |
Wire Gauge | 24 AWG (0.51 mm) |
Twisted Pairs | 4 × UTP, color-striped |
Bandwidth | 350 MHz typ. |
Outer Jacket | CMR riser-rated PVC, green |
Cable Length | 1000 ft (305 m) continuous spool |
Packaging | Tangle-free easy-pull professional box |
Operating Temp | -20 °C → +75 °C |
Standards | UL 444, ISO/IEC 11801, RoHS, ETL Verified |
Part Number | CT-C5E-24-SOLID-1000-GRN |
