H-Tap Compression Connector 250 MCM–2 AWG Cu | 35 kV, UL/CSA Listed
Shipping calculated at checkout
SKU: 8882-006
Out of stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The CT-8882-006 is a tin-plated copper H-tap compression connector designed for parallel tapping of 250 MCM to 2 AWG copper conductors. It provides a single-point connection between a main run conductor and a tap conductor in industrial power distribution, renewable energy installations, and utility service applications. The connector is rated for 35 kV and operates across a temperature range of -40 °C to +90 °C (194 °F).
Specifications
- Conductor range: 250 MCM – 2 AWG Cu (run and tap)
- Material: Tin-plated electrolytic copper
- Voltage rating: 35 kV
- Temperature rating: -40 °C to +90 °C (194 °F)
- Die index: 654
- Crimps: 1 crimp per barrel
- Overall dimensions: 0.90 in × 0.90 in × 1.85 in (L × W × H)
- Cover: Clear, flame-retardant (UL 94 V-0)
- Standards: UL 486A-486B, CSA C22.2 No. 65
Cross-Reference
Form and fit equivalent to Burndy YH2929WCC and comparable H-tap connectors from major manufacturers. Die index 654 ensures crimp tooling compatibility across brands.
FAQ
What crimp tool and die do I need for the CT-8882-006?
Use any manufacturer-specified tool with die index 654. One crimp per barrel is required. Verify your tool's die compatibility before installation.
Can this H-tap be used for aluminum conductors?
No. The CT-8882-006 is specified for copper conductors only: 250 MCM – 2 AWG Cu for both run and tap. Do not install on aluminum or copper-clad aluminum.
