250 kcmil Copper Compression Lug, 1/4" Stud, 1-Hole, Standard Barrel
Shipping calculated at checkout
SKU: CT-SB25014
1000 in stock
Open here
Goes with
The Conversions Tech Copper Standard Barrel One-Hole Compression Lug is a spec-built terminal connector for 250 MCM copper conductors. Engineered for medium-power electrical applications, this lug features a 1/4-inch bolt hole for standard terminal compatibility and a sight window for visual verification of conductor insertion and crimp quality. The tin-plated copper construction provides corrosion resistance while maintaining conductivity. Yellow color coding per industry standards allows for quick field identification. Designed for use in switchgear, panelboards, motor control centers, and power distribution equipment where reliable terminations are critical.
| Specifications | |
| Part number | 210-98032 |
| Conductor | 250 kcmil copper, Class B stranded |
| Stud | 1/4 in, 1 hole |
| Barrel | Standard, 1.10 in (E), chamfered entry, inspection window |
| Overall length | 2.18 in (B) |
| Tongue width | 1.088 Inch |
| Tongue thickness | 0.157 Inch |
| Die | Index 62, Yellow, one crimp |
| Material | Electrolytic copper, electro tin plated |
| Rating | UL 486A, cULus, 90 C, 35 kV, 255 A at 75 C |
| Color code | Yellow |
Specifications
- Conductor Size: 250 MCM copper
- Stud/Bolt Size: 1/4 inch
- Material: Seamless electro-tin plated copper
- Barrel Type: Standard with chamfered entry
- Barrel length: 1.10 inches
- Inner Diameter: 0.593 inches
- Outer Diameter: 0.75 inches
- Pad Dimensions: 0.875" L x 1.088" W x 0.157" thick
- Hole Configuration: 1 hole
- Overall Length: 2.18 inches
- Voltage Rating: 35 kV
- Temperature Rating: 90°C
- Die Index: I-62
- Color Code: Yellow
- Sight Window: Yes
FAQ
What crimping tool and die should I use with this lug?
Use a compression tool with die index I-62. Always verify the die index marking on your tooling before crimping. The sight window allows visual confirmation that the conductor is fully inserted before compression.
Is this lug rated for 90°C conductor ampacity?
Yes. The 90°C temperature rating supports full ampacity of 250 MCM copper conductors per NEC tables. Verify your application does not exceed 35 kV. Temperature rating applies to the lug itself; final assembly ratings depend on complete termination conditions.
Can I use this lug with aluminum conductors?
No. This lug is specified for copper conductors only. The tin plating and barrel dimensions are engineered for copper. Using with aluminum conductors requires a different product rated for that material combination.
Specifications
| Part Number | 210-98032 |
| Category | Electrical connector |
| Weight | 0.21 lb |
Cross-Reference — One-Hole Standard Barrel, 250 kcmil, 1/4 in. stud
This lug crosses to the following parts of the same conductor size, stud and barrel:
| Manufacturer | Part Number |
|---|---|
| Burndy (Hubbell) | YA29L2 |
| Panduit | LCA250-14-X |
| Thomas & Betts (ABB) | 54172-TB |
Crosses by conductor size, stud and barrel from each manufacturer's published catalog. Confirm the die index for your tooling. Trademarks belong to their respective owners and are used for compatibility identification only.
