3/4 in. EMT Raintight Compression Connector, Insulated Throat, Steel | UL 514B | 3104-0034
Shipping calculated at checkout
SKU: 3104-0034
250 in stock
Open here
CT 3104-0034 — 3/4" emt raintight compression connector, insulated throat, zinc-plated steel, thermoplastic throat. For EMT trade size 3/4 (OD 0.922"). UL 514B raintight (wet locations); concrete-tight; insulated throat per NEC 300.4(G). Direct cross for RACO 2913RT.
| Part No. | 3104-0034 |
|---|---|
| Trade size | 3/4 in — fits OD 0.922 in |
| Raceway | EMT |
| Material / finish | Zinc-plated steel, thermoplastic throat |
| Listing | UL 514B raintight (wet locations); concrete-tight; insulated throat per NEC 300.4(G) |
| Package | Sold each; box quantities priced through the trade desk |
Cross-reference
| Manufacturer | Part No. |
|---|---|
| RACO | 2913RT |
Crosses identify fittings of the same trade size, raceway, and listing class. "Class" entries are family-level — confirm the exact number on the manufacturer datasheet.
Where it's used
- Rooftop and exterior EMT entering enclosures (NEC 358.42 wet-location fittings)
- Wash-down and damp industrial areas
- Any entry for 4 AWG and larger where the insulated throat replaces a bushing
How to install
Tighten the gland nut until the sealing ring is visibly compressed against the tube; locknut inside wrench-tight. Do not reuse the sealing ring. Guide: EMT Fittings Guide — Set-Screw vs Compression vs Raintight (NEC 358).
Complete the run — 3/4 in.
Coupling · Locknut · Bushing · Grounding bushing · One-hole strap · Hanger
Stocked in Oxnard, CA — same-day shipping on orders by 2PM ET. Volume and trade pricing through the trade desk.
