Key Advantages

• Ultra-Efficient 1 W LED – Saves battery amp-hours; cool-running solid-state driver.
• 12 V DC Ready – 10–15 V input range with reverse-polarity & EMI protection.
• Vibration-Rated – IEC 60068-2-6 compliant for RV, marine & bus installations.
• Brushed-Nickel Bezel – Marine-grade PVD finish resists corrosion & fingerprints.
• Crystal-Clear Acrylic Optic – CNC-cut lens delivers uniform, glare-free 3000 K beam.
• Low-Profile Housing – Just ⅝″ (15 mm) thick; stealth surface-mount design.
• 50 000 h L70 Lifespan – Maintenance-free illumination for years on the road.

Technical Specifications

• Operating Voltage: 10 – 15 V DC (12 V nominal)
• Power Draw: 1 W (≈ 83 mA @ 12 V)
• Luminous Flux: 110 lm ±5 %
• Color Temperature: 3000 K warm white, 90 CRI
• Housing Size: Ø 100 mm × 15 mm (4″ × ⅝″)
• Ingress Rating: IP40 (interior)
• Mounting: Two-screw surface mount; gasketed back plate
• Housing Material: 6063 aluminum, brushed-nickel PVD
• Optic: CNC acrylic lens; ±1 % tolerance
• Compliance: SAE J1455 vibration, RoHS 3
• Lifespan: > 50 000 h L70 @ 25 °C

Built for Mobile & Marine Interiors

Ideal for RV ceiling pods, boat cabins, bus passenger bays, and camper trailers. Wire directly to house-battery 12 V circuits for flicker-free, glare-controlled task lighting that preserves battery life and withstands miles of vibration.
