LiFePO₄ 12V / 24V Deep Cycle Battery Series | 100Ah · 200Ah · 300Ah | IP65 | 6000 Cycles | Conversions Tech INC.
The Conversions Tech LiFePO₄ Deep Cycle Battery Series offers exceptional reliability, safety, and energy density for power systems, solar storage, electric vehicles, and marine applications. Available in 12V and 24V configurations with capacities from 100Ah to 300Ah, these batteries deliver up to 6000 life cycles and feature an integrated smart BMS with temperature protection and IP65-rated enclosure. Designed for long service life and consistent output, they are ideal for renewable energy, mobility, and industrial power systems.
General Technical Specifications
| Battery Type | Solid-State LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage | 12.8V / 25.6V (12V & 24V Systems) |
| Nominal Capacity | 100Ah · 200Ah · 300Ah |
| Energy | 1280Wh (100Ah) · 2560Wh (200Ah) · 3840Wh (300Ah) |
| Cycle Life | ≥ 6000 Cycles (0.2C, 25°C / 77°F) |
| Self-Discharge | < 3% per month |
| Charge Voltage | 14.6V ± 0.2V (12V) · 29.2V ± 0.2V (24V) |
| Charge Mode | 0.2C Constant Current to 14.6V, then Constant Voltage |
| Max Discharge Current | 100A (12V 100Ah) · 150A (12V/24V 200Ah–300Ah) |
| Max Charge Current | 100A (Standard) · 150A (Customizable) |
| BMS Protection | Integrated Smart BMS with Temperature & Overcurrent Protection |
| Operating Temperature | Charge: 0°C to 45°C (32°F–113°F) · Discharge: -20°C to 60°C (-4°F–140°F) |
| Storage Temperature | 0°C to 40°C (32°F–104°F) |
| Humidity Range | 60 ± 25% Relative Humidity |
| Temperature Cut-Off | Charge Cut-off @ 0°C · Discharge Cut-off @ 60°C |
| Enclosure Protection Level | IP65 — Dustproof & Water-Resistant |
| Parallel / Series Connection | Max 4P or 4S4P Configurations |
| Certifications | CE · UN38.3 · MSDS · RoHS |
| Warranty | 5-Year Limited Warranty (Optional 10-Year Extension) |
Model-Specific Details
| Model | Nominal Voltage | Capacity | Dimensions (mm / in) | Weight (kg / lb) |
|---|---|---|---|---|
| 12.8V 100Ah (LFP12-100) | 12.8V | 100Ah | 332 × 176 × 221 mm (13.07 × 6.93 × 8.70 in) | 12 kg (26.46 lb) |
| 12.8V 200Ah | 12.8V | 200Ah | 522 × 238 × 218 mm (20.55 × 9.37 × 8.58 in) | 19.2 kg (42.33 lb) |
| 12.8V 300Ah | 12.8V | 300Ah | 522 × 238 × 218 mm (20.55 × 9.37 × 8.58 in) | 19.2 kg (42.33 lb) |
| 25.6V 100Ah | 25.6V | 100Ah | 522 × 238 × 218 mm (20.55 × 9.37 × 8.58 in) | 19.2 kg (42.33 lb) |
Voltage Parameters
- 12V Models: Absorption Voltage 14.2–14.6V · Float Voltage 13.5–13.6V
- 24V Models: Absorption Voltage 28.4–29.2V · Float Voltage 27–27.2V
Key Features & Benefits
- Advanced LiFePO₄ Chemistry: Delivers superior safety, thermal stability, and long cycle life.
- Smart BMS Integrated: Protects against overcharge, over-discharge, temperature, and short-circuit events.
- 6000+ Life Cycles: Provides 10× longer lifespan than traditional lead-acid batteries.
- Lightweight & Compact: 50% lighter than comparable AGM batteries for easy installation.
- IP65 Protection: Suitable for outdoor, marine, and mobile environments.
- Fast Charging: Fully recharges in 2–3 hours with compatible chargers.
Applications
- Solar and renewable energy storage systems
- Electric vehicles, bikes, and scooters
- Boats, golf carts, and marine power systems
- Electric wheelchairs and portable power systems
- Home energy storage and UPS systems
Operating Environment
- Charging: 0°C to 45°C (32°F to 113°F)
- Discharging: -20°C to 60°C (-4°F to 140°F)
- Storage: 0°C to 40°C (32°F to 104°F)
- Humidity: 60 ± 25% RH
Why Choose Conversions Tech INC?
- Industrial-Grade Design: Built for off-grid, automotive, and marine applications.
- Extended Service Life: 6000+ cycles with minimal maintenance.
- Certified Safety: Meets CE, UN38.3, MSDS, and RoHS international standards.
- Expandable Power: Connect up to 4 units in series or parallel for larger systems.
- 5-Year Warranty: Backed by comprehensive Conversions Tech INC warranty and technical support.
Frequently Asked Questions (FAQs)
1. How many life cycles does this battery provide?
Each battery delivers 6000+ cycles at 80% DOD under normal use, lasting up to 10 years.
2. Can I use these batteries in series or parallel?
Yes — you can connect up to 4 units in series (4S) or in parallel (4P) for system scalability.
3. Is the BMS included?
Yes — each battery includes a built-in Smart Battery Management System for safety and performance monitoring.
4. Are these batteries waterproof?
Yes — they are IP65-rated for dust and water resistance.
5. Can these be used with solar systems?
Absolutely — perfect for off-grid solar, hybrid inverters, and home energy storage systems.
6. How do I charge this battery?
Use a compatible LiFePO₄ charger with absorption voltage of 14.2–14.6V (12V) or 28.4–29.2V (24V).
