TECHNICAL GUIDE
Choosing the Right HDMI Cable
Two things determine whether an HDMI cable works for your installation: the speed certification class and the length/gauge combination. Brand names matter far less than these two specs.
HDMI 2.0 vs HDMI 2.1
| Spec | HDMI 2.0 (18G) | HDMI 2.1 (48G) |
|---|---|---|
| Max video | 4K @ 60Hz | 4K @ 120Hz, 8K @ 60Hz |
| Bandwidth | 18 Gbps | 48 Gbps |
| Use for | Conference rooms, digital signage, most TVs | Gaming (120Hz), 8K, eARC audio systems |
Length and gauge
Copper HDMI is reliable to about 25 ft at full bandwidth with 28 AWG conductors; heavier 26-24 AWG extends reach. Past 35-50 ft, use an Active Optical Cable (AOC) - fiber inside an HDMI jacket, good to 300 ft with zero signal loss.
| Run | Recommendation |
|---|---|
| 3-15 ft | 28 AWG copper, 2.0 or 2.1 per source |
| 15-35 ft | 28-26 AWG copper 2.1 (our 25/30/35 ft) |
| 35-300 ft | AOC fiber HDMI |
In-wall installs
For cable inside walls or plenum spaces, code requires CL2/CL3 (or plenum) rated jackets per NEC Article 800-class rules. Check the jacket print, not the box.
Why buy distributor-direct
Certification class is binary - an 18G or 48G cable either passes or it does not. Our cables are built to the same speed classes sold by AudioQuest ($30-90) and Monoprice ($10-35) at $2-15 distributor pricing, with volume terms for AV integrators.
