Cantilever Rack Shelf, 19 in, 20 kg | 1U and 2U, 300 to 400 mm Deep | CTA-0103 / CTA-0104
Shipping calculated at checkout
SKU: CTA-0103-300-B
In stock
Open here
Cantilever shelf for 19 in racks and wall cabinets, 20 kg rated, SPCC steel, RAL 9005 black.
- Front mount only, no rear support needed, ideal for wall cabinets and 2-post racks
- 1U (43 mm) and 2U (86 mm) heights in 300, 350 and 400 mm depths
- Vented deck, supplied with cage nuts and screws
- Electrostatic powder coat, individually boxed
Ordering information
| Part No. | Height | W (mm) | D (mm) | Load |
|---|---|---|---|---|
| CTA-0103-300-B | 1U | 483 | 300 | 20 kg |
| CTA-0103-350-B | 1U | 483 | 350 | 20 kg |
| CTA-0103-400-B | 1U | 483 | 400 | 20 kg |
| CTA-0104-300-B | 2U | 483 | 300 | 20 kg |
| CTA-0104-350-B | 2U | 483 | 350 | 20 kg |
| CTA-0104-400-B | 2U | 483 | 400 | 20 kg |
Engineered for 19 in racks to ANSI/EIA-ECA-310-E. Same-day shipping on in-stock items. Browse the full Racks & Cabinets line or download the CT-40 catalog from our catalog library.
