Long Barrel Compression Lug, 1-Hole, 1/0 AWG, 3/8 in Stud | Tin-Plated Copper, Chamfered Entry, Die Index 42 Pink, UL 486A 90 C, Flex-Rated | CT-LB1-0-38
Shipping calculated at checkout
SKU: CT-LB1-0-38
790 in stock
Open here
The CT-LB1-0-38 long barrel one-hole compression lug terminates 1/0 AWG copper on a 3/8 in stud. Seamless electrolytic copper tube, tin plated, with a 1.18 in chamfered-entry barrel that takes two crimps and is listed for Class B stranded and flex-rated for Class C, K and M fine-strand battery, inverter and welding cable. Inspection window shows full strand insertion. Die index 42, pink band, on any 12-ton U-die crimper. UL 486A, cULus, 90 C, 600 V.
| Specifications (dimensions per manufacturer UL data sheet) | |
| Part number | CT-LB1-0-38 |
| Manufacturer catalog number | LB1038 |
| Conductor | 1/0 AWG copper, Class B stranded through M (flex-rated) |
| Stud | 3/8 in, 1 hole |
| Barrel | Long, 1.18 in (E), chamfered entry, inspection window |
| Overall length | 2.26 in (B) |
| Tongue width | 0.738 Inch |
| Tongue thickness | 0.125 Inch |
| Die | Index 42, Pink, two crimps |
| Material | Electrolytic copper, electro tin plated |
| Rating | UL 486A, cULus, 90 C, 600 V, 150 A at 75 C |
| Color code | Pink |
Cross-Reference: CT-LB1-0-38
| Brand | Part | Notes |
|---|---|---|
| Burndy | YA26L-TC38* | long barrel, 1/0 AWG, 3/8 in; die index 42 |
| Panduit | LCB1/0-38-X* | long barrel, 1/0, 3/8 in |
| NSi | L1038* | 1/0, 3/8 in; same class |
| Thomas and Betts | 54110-TB* (long barrel) | Color-Keyed pink, index 42 |
| ILSCO | CRB-1/0-38* | same class |
*Cross by conductor size, stud size, barrel length and die index; verify for your application. Trademarks belong to their owners. Other studs: 1/2 in, 210-98070. Short barrel 1/0 on 3/8 in: 210-98019. Crimping: die chart; bolt torque: torque chart; matching die: index 42 U-die. In stock, ships same day; contractor and distributor pricing.
