Long Barrel Copper Compression Connector 250 MCM | 35 kV, 90°C, Center
Shipping calculated at checkout
SKU: 212-5250
900 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
Long barrel compression connector for 250 MCM copper conductors. Center wire stop design with chamfered barrel end for wire insertion. Tin-plated seamless copper body rated 35 kV and 90°C. Blue color code for size identification. Used in grounding and bonding applications across power distribution, industrial machinery, renewable energy systems, electrical enclosures, commercial buildings, telecommunications infrastructure, and data centers.
Specifications
- Conductor Size: 250 MCM
- Barrel Type: Long with chamfered end
- Overall Length: 3.875 inches
- Inner Diameter: 0.59 inch
- Outer Diameter: 0.75 inch
- Wire Stop: Center
- Body Material: Electro-tin plated high strength seamless copper
- Conductor Material: Copper
- Voltage Rating: 35 kV
- Temperature Rating: 90°C
- Color Code: Blue
- Application: Grounding and bonding
Cross-Reference
Equivalent form factor to long barrel compression connectors from major electrical manufacturers. Specified by Conversions Tech engineering team and built to specification by certified partner factories.
FAQ
What crimping tool is required for this connector?
Use a compression tool rated for 250 MCM copper connectors. Follow the manufacturer's die index and number of crimps as marked on the connector barrel.
Is this connector suitable for wet locations?
The source specifications do not include environmental ratings. Verify suitability for your specific installation environment against applicable NEC and local code requirements.
Does the center wire stop affect installation depth?
Yes. The center wire stop positions the conductor at the correct insertion depth for full barrel contact. Strip conductor length to match the visible chamfered entry point to the wire stop location.
