Copper Short Barrel Two Hole Compression Lugs 4/0 AWG 5/16-inch Bolt Size
Shipping calculated at checkout
SKU: 210-98055A
1000 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
The Conversions Tech 2-Hole Copper Compression Lug is a reliable and durable connector designed for secure electrical connections. Built for 4/0 AWG conductors, it features a 5/16-inch bolt size and a 2-hole configuration, ensuring a stable and robust connection. The standard barrel design allows for efficient crimping, while the sight window facilitates easy inspection during installation, ensuring a proper crimp every time. The tin-plated finish offers enhanced corrosion resistance, and the distinctive yellow color code ensures quick identification, making this lug a dependable choice for long-lasting performance and secure connections in various electrical applications.
Key Features
- 4/0 AWG Conductor Size: Designed for securely terminating 4/0 AWG conductors, making it suitable for high-power electrical systems.
- 5/16-Inch Bolt Size: Provides a strong, stable connection with a 5/16-inch bolt size, ensuring reliable attachment to terminals or equipment.
- 2-Hole Configuration: Dual attachment points ensure a stable and reliable connection, ideal for demanding electrical applications.
- Standard Barrel Design: Facilitates easy crimping with compression tools, ensuring a secure and efficient connection.
- Sight Window: Allows for clear visual inspection during installation, ensuring the crimp is properly made for maximum reliability and performance.
- Tin-Plated Finish: Enhances corrosion resistance, extending the connector's lifespan and providing protection from environmental factors.
- Yellow Color Code: Ensures quick and easy identification, simplifying the installation process and reducing the risk of installation errors.
-
Durable and Reliable: Built to provide long-lasting performance, making it an excellent choice for a variety of industrial, commercial, and electrical applications.
Technical Specifications
| Material | Seamless Electro-Tin Plated Copper |
|---|---|
| Color | Yellow |
| Overall Length | 3.303 Inches |
| Barrel Length | 0.875 Inch |
| Conductor Material | Copper |
| Voltage Rating | 35 kV |
| Conductor Size | 4/0 AWG |
| Stud Size | 5/16 Inch |
| Die Index | I-54 |
| Pad Size | 1.937 Inch L x 0.999 Inch W x 0.141 Inch Thk |
| Pad Holes | 2 |
| Pad Hole Spacing | 1 Inch |
| Barrel Type | Standard |
| Inner Diameter | 0.546 Inch |
| Outer Diameter | 0.687 Inch |
| Cable Entry | Chamfered Type |
| Temperature Rating | 90 Deg C |
