Aluminum Splicer-Reducer, 6 AWG to 4/0 AWG, Each | In-Line Set-Screw Splice, Dual-Rated AL9CU, UL 486B | 61103HD
Shipping calculated at checkout
SKU: 61103HD
36 in stock
Open here
The 61103HD dual-rated aluminum splicer-reducer joins or reduces conductors across 6 AWG to 4/0 AWG in a single tin-plated aluminum barrel with hex set-screw terminations: the fast, re-enterable alternative to a crimped splice for service entrance, panelboard feeder and tap-reduction work. AL9CU dual-rated for copper and aluminum, UL 486B class, 600 V, 90 C. Sold each; insulate with two half-lapped layers of rubber splicing tape and vinyl, or a listed heat-shrink sleeve, to the insulation level of the conductors.
Applications
- Service entrance conductor splices and repairs
- Reducing feeder taps to branch-circuit sizes, 6 AWG to 4/0
- Panelboard and meter-base conductor extensions
- Aluminum-to-copper transitions with oxide inhibitor; no crimping tool, re-enterable
| Specifications | |
| Part number | 61103HD |
| Conductor range | 6 AWG to 4/0 AWG, copper or aluminum, stranded or solid, each end |
| Body | 6061 aluminum, electro tin plated, two hex set screws per end |
| Rating | 600 V, 90 C, UL 486B class, AL9CU |
| Torque | 6 to 4 AWG 45 lb-in; 3 to 1/0 50 lb-in; 2/0 to 4/0 250 lb-in (3/8 in hex) |
| Weight | 0.70 lb |
Cross-Reference: 61103HD
| Brand | Part | Notes |
|---|---|---|
| ILSCO | SPA-4/0* | dual-rated aluminum splicer-reducer, same class; match by 6 AWG to 4/0 range |
| Morris Products | 90615* | match by range and UL 486B class |
| Burndy | AMS series* | aluminum mechanical splice, match by range |
| Polaris (NSI) | IPL series | pre-insulated alternative; see insulated multi-taps |
*Cross by conductor range and UL 486B class; verify for your application. Trademarks belong to their owners. In stock and ships same day. Guide: split bolt vs C-tap vs multi-tap. Contractor and distributor pricing.
