Two-Hole Long Barrel Compression Lug 2 AWG 1/2" Stud, 1.75" NEMA Spacing | 90°C 170A Tin-Plated Copper, UL 486A | CT-LB2-12-N
Shipping calculated at checkout
SKU: CT-LB2-12-N
Out of stock
Open here
Two-hole long barrel copper compression lug for 2 AWG Class B stranded copper conductor. Two 1/2 inch stud holes on true 1-3/4 inch NEMA centers for switchgear, panelboard and transformer pads. Seamless electro tin plated copper, chamfered barrel entry, barrel stamped with conductor size and die colour code (Brown, die index 33). Extended barrel accepts two crimps.
Specifications
- Wire size: 2 AWG copper
- Stud size: 1/2"
- Hole spacing: 1.75" (NEMA 2-hole)
- Configuration: two hole, long barrel
- Material: tin-plated copper
- Colour code: Brown (die index 33)
- Temperature rating: 90°C
- Standard: UL 486A/B listed
Case pricing and net terms available for trade accounts. Same-day shipping on in-stock items.
