Long Barrel Two-Hole Compression Lug 250 MCM 1/2" | 600V-35kV, 90°C, UL
Shipping calculated at checkout
SKU: 210-09973
1000 in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
Long barrel two-hole compression lug for terminating 250 MCM copper conductors in industrial, commercial, and utility power distribution systems. Electro tin-plated seamless copper construction with white color code for conductor size identification. The extended barrel length maximizes contact surface area for secure crimping, while the dual-hole pad provides redundant termination to busbars or equipment terminals. Rated for medium-voltage applications up to 35 kV.
Specifications
- Material: Electro tin-plated high strength seamless copper
- Conductor size: 250 MCM copper
- Stud size: 1/2 inch
- Pad holes: 2
- Pad hole spacing: 1.75 inches
- Pad dimensions: 3" L × 1.088" W × 0.157" thick
- Barrel length: 1.688 inches
- Overall length: 5.219 inches
- Wire strip length: 1.75 inches
- Voltage rating: 600V to 35 kV
- Temperature rating: 90°C
- Die index: I-62
- Color code: White
- UL Listed
Cross-Reference
Equivalent to long-barrel two-hole compression lugs from major manufacturers including Burndy, Panduit, and Ilsco for 250 MCM copper conductor terminations. Die index I-62 compatibility ensures tooling interoperability with standard industry crimping equipment.
FAQ
What crimping tool is required for this lug?
Use a compression tool with die index I-62. Verify die compatibility with your specific tool manufacturer before crimping.
Is this lug suitable for medium-voltage applications?
Yes. The 600V to 35 kV voltage rating accommodates low-voltage distribution through medium-voltage industrial applications. Confirm installation meets applicable NEC and local code requirements for your specific voltage class.
Why does the pad have two holes?
The dual-hole design provides mechanical redundancy for critical connections and allows termination to two separate studs or a wider busbar configuration. The 1.75-inch hole spacing matches standard busbar drilling patterns.
