Audio Video Adapter | Displayport to VGA
Shipping calculated at checkout
SKU: DP-VGA
In stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
Conversions Tech Active DisplayPort-to-VGA Converter
Seamlessly bridge modern DisplayPort™ sources with legacy VGA displays—no drivers, no external power.
Key Advantages
- 1920 × 1200 / 1080p support at full 60 Hz
- 10-bit Triple-DAC outputs clean 700 mVpp RGB
- EDID Pre-Fetch for instant link training & flawless handshake
- Spread-Spectrum Clocking lowers EMI to meet FCC/CE Class B
- Ultra-Low Power – 1.4 W active, 0.1 W standby (drawn from DP pin-20)
Technical Specifications
| Parameter | Value |
|---|---|
| DisplayPort Input | DP 1.1a, 1–2 lanes @ 2.7 Gb/s/lane |
| Max Pixel Clock | 154 MHz @ 8 bpc (1920×1200 60 Hz) 144 MHz @ 10 bpc (1920×1080 60 Hz) |
| Analog Output | 0–700 mVpp RGB, 75 Ω source |
| EDID Handling | On-chip ROM – VGA template (auto pre-fetch) |
| EMI Mitigation | ±0.5 % spread-spectrum modulation |
| Power Draw | Active 1.4 W | Standby 0.1 W (3.3 V DP rail) |
| Hot-Plug Detect | DP HPD + DDC sink presence sensing |
Perfect For
Conference-room podiums • Projector QA lines • Control-room consoles • Digital signage players • Training labs with mixed-signal fleets
4 Reasons Pros Buy Direct from Conversions Tech
Headquartered in business-friendly Wyoming, we design, test, and ship every product from inside the United States—delivering genuine “Made-for-America” quality without the big-box markup.
Our in-house team owns every CAD file, mold, and QA station behind our weatherproof boxes, conduit bodies, and power inverters. Vertical control means tighter tolerances, UL-listed safety, and up to 30 % lower cost than private-label imports.
Thousands of SKUs sit ready to go. Orders placed by 2 p.m. ship the same day, keeping contractors, OEMs, and distributors on schedule.
Need a torque spec or an OEM quote at dawn? You’ll speak directly with the Conversions Tech engineering desk—not a script reader—for instant answers, custom kitting, and private-label options.
Bottom line: For rugged, code-compliant electrical solutions shipped fast from a trusted U.S. source, choose Conversions Tech and build it right the first time.
