RG6 Coaxial Cable — Dual Shield (Gray, 1000 ft Pull Box)
Sigma Wire’s Gray RG6 Coaxial Cable sets a new standard in signal transmission. Precision-engineered to reduce signal loss and enhance frequency response, this 1000-ft pull box is built for professional installations and advanced home setups alike. With dual shielding and a rugged PVC jacket, it delivers clean, reliable performance even in high-interference environments.
Key Features
- Temperature Range: –40 ℃ to 75 ℃
- Voltage Rating: 30 V
- Certifications: CSA, ETL, UL, CM rated for residential and commercial use
- Conductor: 18 AWG Copper-Clad Steel, 1.02 mm diameter
- Shielding: Dual-layer (bonded aluminum foil + 36 AWG aluminum braid)
- Insulation: Foam PE, dielectric diameter 4.57 ± 0.01 mm
- Jacket: PVC, 6.93 ± 0.2 mm, with ≥2% carbon content for durability and UV resistance
- Nominal Capacitance: 53 ± 0.1 nF/km
- Impedance: 75 Ω ± 1.5
- Bending Radius: Supports S & U bends, minimum 1.5 cm
Mechanical Properties
| Impact Test @ –15 ℃ | No visible jacket damage |
| Cold Bend Test @ –40 ℃ | No visible jacket damage |
| Max Jacket Ovality | 7% |
| Max Dielectric Ovality | 7% |
| Max Jacket Eccentricity | ≤ 10% |
Electrical Properties
| DC Resistance (Inner) | 100 Ω/km ± 1 |
| DC Resistance (Outer) | 18 Ω/km ± 0.5 |
| Return Loss | ≥ –20 dB |
| Velocity of Propagation | ≥ 82% |
Applications
- CATV & Satellite: Ensures clean video and audio signals for television and satellite systems.
- Professional Baseband Video: BNC-compatible for high-fidelity video transmission.
- Consumer A/V Systems: Adaptable to RCA and other connectors for versatile audio-visual setups.
Packaging & Availability
- Length: 1000 ft per pull box
- Color: Gray, easy to identify among other cable runs
- Packaging: Convenient Reel-N-Box design; pallet quantities of 20 or 30 available
Why Choose Sigma Wire?
Every reel of Sigma Wire RG6 is manufactured with meticulous attention to performance and durability. Tested for impact, cold bend, and electrical consistency, it maintains uniform impedance and minimal signal attenuation across long runs. Backed by CSA, ETL, and UL certifications, this cable is ready for both residential and commercial installs. Whether you’re building CATV networks, wiring a broadcast system, or upgrading a home theater, Sigma Wire’s RG6 Coaxial Cable is the professional choice for clean, reliable signals.
